Panduit® Pan-Lug™ LCC250-12-X 2-Hole Compression Connector Lug, 250 kcmil Stranded Copper Conductor, Die Code: P62, 1/2 in Stud, Tin Plated Copper
$19.67 / Each
Regular Price: $28.10, you save $8.43 (30%)- Type :Compression
- Stud Size :1/2 in
- Voltage Rating :35 kV
- Color :Yellow
- Material :Copper
- Number of Bolt Holes :2
Technical Specifications
Brand
Type
Compression
Stud Size
1/2 in
Voltage Rating
35 kV
Color
Yellow
Material
Copper
Number of Bolt Holes
2
Conductor Size
250 kcmil
Conductor Type
Stranded Copper
Dimensions
1.6 in L x 1.17 in W
Finish
Tin Plated
Manufacturer Name
Panduit
Panduit® Pan-Lug™ Compression Connector Lug, 2-Hole, Series: LCC, Stranded Copper Conductor, 250 kcmil Conductor, Die Code: P62, 35 kV, 1/2 in Stud, Standard/Straight Tongue, 1.17 in W x 0.14 in THK Tongue, 5.23 in Overall Length, Long Barrel, 0.63 in ID x 0.77 in OD x 1.6 in L Barrel, 1-11/16 in L Wire Strip, 1-3/4 in Stud Hole Spacing, 90 deg C, 1-11/16 in Mounting Hole, Tin Plated Copper, Yellow
