Panduit® Pan-Lug™ LCA6-14-L 1-Hole Compression Lug Connector With Inspection Window, 6 AWG Stranded Copper Conductor, Die Code: P24, 1/4 in Stud, Copper
$2.23 / Each
Regular Price: $3.18, you save $0.96 (30%)- Type :Compression
- Stud Size :1/4 in
- Voltage Rating :35 kV
- Color :Blue
- Material :Copper
- Number of Bolt Holes :1
Technical Specifications
Brand
Type
Compression
Stud Size
1/4 in
Voltage Rating
35 kV
Color
Blue
Material
Copper
Number of Bolt Holes
1
Conductor Size
6 AWG
Conductor Type
Stranded Copper
Dimensions
0.81 in L x 0.48 in W
Finish
Tin Plated
Manufacturer Name
Panduit
Panduit® Pan-Lug™ Compression Lug Connector, 1-Hole, Series: LCA, Stranded Copper Conductor, 6 AWG Conductor, Die Code: P24, 35 kV, 1/4 in Stud, Straight Tongue, 0.48 in W x 0.08 in THK Tongue, 1.61 in Overall Length, Standard/Inspection Window Barrel, 0.22 in ID x 0.31 in OD x 0.81 in L Barrel, Specifications: 7/8 in L Wire Strip, Tin Plated, 90 deg C, 7/8 in Mounting Hole, Copper, Blue
