Panduit® Pan-Lug™ LCA250-12-X 1-Hole Compression Lug Connector With Inspection Window, 250 kcmil Stranded Copper Conductor, Die Code: P62, 1/2 in Stud, Copper
$12.97Â /Â Each
Regular Price: $18.53, you save $5.56 (30%)- Type :Compression
- Stud Size :1/2 in
- Voltage Rating :35 kV
- Color :Yellow
- Material :Copper
- Number of Bolt Holes :1
Technical Specifications
Brand
Type
Compression
Stud Size
1/2 in
Voltage Rating
35 kV
Color
Yellow
Material
Copper
Number of Bolt Holes
1
Conductor Size
250 kcmil
Conductor Type
Copper
Dimensions
2.78 in L x 1.17 in W
Finish
Tin Plated
Manufacturer Name
Panduit
Panduit® Pan-Lug™ Compression Lug Connector, 1-Hole, Series: LCA, Stranded Copper Conductor, 250 kcmil Conductor, Die Code: P62, 35 kV, 1/2 in Stud, Standard/Straight Tongue, 1.17 in W x 0.14 in THK Tongue, 2.78 in Overall Length, Standard/Inspection Window Barrel, 1-1/4 in L Barrel, Specifications: 1-5/16 in L Wire Strip, Tin Plated, 90 deg C, 1-5/16 in Mounting Hole, Copper, Yellow
