IDEALĀ® WEATHERPROOFĀ® 30-1163 63Ā® Series Wire Connector, Winged Shell, Live Action/Square Wire Spring, 16 to 6 AWG Solid/Stranded Copper Wire, Thermoplastic Polyester
$45.98Ā /Ā Package
Regular Price: $56.08, you save $10.09 (18%)- Wire Type :Solid/Stranded Copper
- Voltage Rating :600 VAC
- Color :Gray
- Material :Thermoplastic Polyester
- Temperature Rating :105 deg C
- Dimensions :0.81 in Dia x 1.0625 in W x 1.59375 in H
Technical Specifications
Brand
Wire Type
Solid/Stranded Copper
Voltage Rating
600 VAC
Color
Gray
Material
Thermoplastic Polyester
Temperature Rating
105 deg C
Dimensions
0.81 in Dia x 1.0625 in W x 1.59375 in H
Manufacturer Name
Ideal Industries
Series
63® Series
Wire Size
16 to 6 AWG
IDEALĀ® WEATHERPROOFĀ® Wire Connector, Series: 63Ā® Series, Winged Shell Style, Live Action/Square Wire Spring, Solid/Stranded Copper Wire, 16 to 6 AWG Wire, 600 VAC, Specifications: 5/8 in Wire Strip, (3) 14 AWG Minimum, (2) 8 AWG, (1) 10 AWG Maximum Conductor Combination Size, 105 deg C, Thermoplastic Polyester, Gray, 0.81 in Dia x 1.0625 in W x 1.59375 in H Dimensions
